Patch-Up Pickup

Part 2: Skinning a Rusty Cab Corner

As long as ol’ trucks are prone to corrosion, we’ll stay busy around here—same as anywhere.

- Advertisement -
It’s time to get this rustectomy underway. For starters, a few passes with a 3-inch Roloc-type disc on one of Harbor Freight’s angle die grinders will highlight factory spot welds. This’ll help elderly eyeballs with the next step.

Upon moving our operation from Southern California to northwestern Montana we made a surprising discovery. Old trucks here don’t rust much more than they do there. Sittin’ out to pasture, off the road, away from snow-melting salt brine and magnesium chloride, precious sheetmetal stands a decent chance for survival. Even so, we’re glad to have our rust-repair skillsets—for the future, if we ever finish the job we brought with us.

The 1955 second-series Chevy we’ve been building for so long is a California truck. With the usual rust in the usual places, its cab will be an easy save, made even easier thanks to Brothers Truck Parts for the options they offer. Earlier we opted to replace our left fender and door with brand-new reproduction panels. On the right side we’re patchin’ things up.

Ordinarily we don’t much care for oily lubricants this close to bare steel. For this spendy little spot weld reamer we’ll make an exception, but just an occasional dip now ’n’ then. Here we’re reaming just deep enough to release the skin.

If you were with us last time, you witnessed fairly typical door corner repairs. For that we used sections of an outside door bottom patch panel from Brothers. At the end of that phase we were pleased with our results—except for one little detail. The time we’d invested added up. In the end it would have covered the cost of a brand-new Brothers door shell, shipped all the way to Montana, and then some. Since that’s not our customer’s fault, we’re absorbing the difference. We don’t expect to make that up, but we do expect to do better on the next phase—the replacement of one rusty cab corner.

- Advertisement -

Like so many others, our project truck has been a truck. It’s done its share of work. It’s been crashed ’n’ smashed as well. From some previous impact, the rusty right cab corner’s skin is torn loose down low already. For the repair, a brand-new Brothers lower cab corner should get us off to a good start. Once the inside is accessible we’ll have some straightening to do there. While we’re at it, we’ll take steps to chemically contain other ticking time bombs, like less-advanced corrosion between panels, where pneumatic implements of restoration won’t easily reach.

For us, patchin’ goes smoother when corners like this one are rounded. Our mix-matched hole saw selection had some gaps, so we picked up a new set from Harbor Freight. Here a dull Sharpie through the center marks the spot.

First things first, before sparks fly, the truck is raised on stands to a comfortable work height. As we prepare to tag-team the job at hand, we’re not expecting’ any unusual challenges. In the past we’ve found Brothers patch panels to be quite accurate, so this won’t be about fancy metalshaping. As usual we’ll try to keep our repair as small as possible. Since we’ll be using only one section of the reproduction patch panel there might be something left for someone else down the road.

So, what about the rusty chunk that we’ll cut away? With P-word patina being in style as it is, could there now be a use for such scrap? We’ve got an ol’ truck to work on first, but later on, perhaps we’ll see.

Brothers Truck Parts
(800) 977-2767

- Advertisement -

Harbor Freight Tools
(800) 423-2567

Summit Racing Equipment
(800) 230-3030
