X vs. H Pipes

The Exhausting Facts

By Jeff Smith   –   Photography by the Author and Courtesy of the Manufacturers

“H-pipes–nah–they don’t do anything.”

“Man, you absolutely have to have X-pipes–they add 20 hp!”

We’ve all heard the comments and claims. Frankly, neither statement is correct or even close to accurate. So, instead of listening to your sister’s husband’s nephew, let’s dig into a few facts.

- Advertisement -

We’ll start with the huge claims of horsepower increase and perhaps save you some time. There are small improvements in power with H and X pipes but the gains must underscore the word small. If you’re expecting 20 hp you will be better off looking at a cam swap or headers over stock manifolds because you won’t find more than 1 percent increases with either an H- or an X-pipe.

So why go through the effort?  The main reason most people will opt for an H- or an X-pipe has more to do with a change in pitch. This is especially true with an X-pipe. This leads us into more of the details involved with which system might do more for your particular application.

001 This is a universal H pipe kit that can be added to literally any dual exhaust system
This is a universal H-pipe kit that can be added to literally any dual exhaust system with 2½-inch-diameter pipes. This particular kit is from Summit Racing but there are many others in diameters from 2¼ to 4 inches.

Check it out: Tips on Choosing and Installing a Starter

- Advertisement -

The exhaust noise generated by an internal combustion engine is generally attributed to sound pressure that travels in pulses or waves through the exhaust system. Every time an exhaust valve opens, a pressure wave travels through the primary pipes of the headers into the collector and into the exhaust pipe.

Because of the uneven firing patterns of a typical V-8, these exhaust pulses do not occur evenly. On the left (odd cylinder numbers) side of a small- or big-block Chevy, in the course of a 720-degree complete cycle of the firing order, there is a sequence when there is a 180-degree portion of crank rotation where no cylinder fires on that bank and another 180-degree sequence when two cylinders fire 90 degrees apart.

002 X pipe–style dual exhaust system for an early Camaro
This is a 2½-inch X-pipe–style dual exhaust system for an early Camaro that is part of the Flowmaster American Thunder series, using a pair of two-chamber, Super 44 welded steel mufflers. Even with the X-pipe, this system is more than a bit loud with the two-chamber mufflers. If you are 18 years old, you’ll love it.

This uneven pressure spikes occur in both sides of a dual exhaust system and tend to increase backpressure in the separate pipes. If you want to see this for yourself, you can take an ordinary low-pressure gauge that reads 0-5 or 0-10 psi and tap into one exhaust pipe just behind the header collector with a -3 or -4 line to the pressure gauge. At idle, if the pressure gauge is not heavily damped, it will display pressure spikes as the needle bounces irregularly between high and low pressure. This is an indication of the high- and low-pressure pulses occurring in each exhaust pipe.

This indicates how one exhaust pipe between the header collector and the muffler experiences both high- and low-pressure areas. The idea behind an H- or X-pipe is to minimize the pressure spikes on both pipes by adding volume to the exhaust at that location. This contributes to minor improvements in flow.

- Advertisement -
003 SpinTech X pipe crossover system with the X located behind the transmission and driveshaft loop to provide additional ground clearance
This is a nice example of a SpinTech X-pipe crossover system with the X located behind the transmission and driveshaft loop to provide additional ground clearance.

Reading more: High-Zoot Paint from Affordable Equipment

The original H-pipe is a simple 90-degree connector, usually of the same diameter as the exhaust pipe, placed in a suitable position between the two pipes. Don Lindfors, who until recently spent many years with Patriot Exhaust systems, told us that their experiments with H-pipes revealed that often the location of the cross-over pipe could result in slight additional power improvements, but that often this location was very close to (or under) the transmission, which is not only inconvenient but also reduces ground clearance.

The more convenient location for the H-pipe is generally farther back in the system where the exhaust pipes are generally closer together. The length of a typical H-pipe is more often dictated by the distance between the twin exhaust pipes. A longer spread between the pipes will produce a larger volume in the cross-over pipe but is only of minor importance.

004 X type cross over pipes do not have to be located just aft of the collectors
X-type cross-over pipes do not have to be located just aft of the collectors. This is a tight shot of the exhaust at the rear of a ’61 Impala built by Scott Sullivan where he has placed an X-pipe just ahead of the tailpipe exits. The X-frame configuration on the ’61 made placing the cross-over up front all but impossible.

The main reason for incorporating an H-pipe in the exhaust system is to alter the tone of the exhaust and also reduce the drone effect present in large exhaust systems at lower engine speeds. This is especially critical if the system is a 3-inch dual system or larger. Our personal experience with a 3-inch dual exhaust system with welded steel mufflers and an H-pipe was in a street car with 3.55:1 gears and a 200-4R overdrive transmission.

At 70 mph, the engine speed was just under 2,000 rpm and the drone produced by this system was exceptionally bad despite the presence of the H-pipe.  The ultimate cure was to fit the car with a smaller 2½-inch system with an H-pipe and different mufflers, but even that change did not completely eliminate the drone.

Droning is where the exhaust system creates a resonant frequency at lower engine speeds that creates a low-frequency harmonic that is extremely annoying. There appears to be different frequencies created by each of the main three components in a typical dual exhaust system. The main exhaust pipes are one component, the mufflers are a second, and the third are the tailpipes and tips.

005 Scavenger X pipe uses a shallow and gentler approach angle to where the pipes blend together
Flowmaster’s Scavenger X-pipe uses a shallow and gentler approach angle to where the pipes blend together. This creates a larger, D-shaped opening that exposes more of the exhaust pulses to the opposite system. This will also alter the exhaust note compared to tighter bend X-pipes.

Individually, these components will produce a harmonic at a given engine speed. Depending upon the specific application of exhaust pipe diameter and muffler selection, as we experienced with the 3-inch system, these components can produce a harmonic at lower engine speeds that as one wag put it, “it was like sitting inside Keith Moon’s bass drum at a The Who concert!”

It’s beyond the scope of this story to address ways to alleviate this problem but there is evidence that using a “J-pipe” of specific length (determined using some simple math) welded to each exhaust pipe upstream of the muffler creates a quarter-wave resonator that can usually minimize but often not fully alleviate this problem. The issue with smaller performance cars is there is often little room to fit these specific-length pipes. An H- or X-pipe may help reduce the intensity, but they will not eliminate the drone.

Testing by several exhaust companies and the automotive media has shown that adding an X-pipe offers similar yet minor power advantages but also integrates a different sound quality to the exhaust. Placement of the X-pipe is also dependent on specific applications but for most street cars this will again result in a similar position to the H-pipe just behind the transmission.

006 x pipe system in the lead photo is the one in this early Camaro RS
The x-pipe system in the lead photo is the one in this early Camaro RS used to ensure plenty of ground clearance but also gives the exhaust note a somewhat higher pitch than that of an H-pipe system.

Because of the X-pipe’s creation, this can often lead to difficulties in adapting it to an existing dual-exhaust system. The best approach is to purchase a complete system that is created for your particular application. But when this is not possible, a custom system can be created. A good exhaust system shop can produce a very nice system without too much trouble as long as there is sufficient room under the vehicle. This is where trucks have a decided advantage over smaller, more cramped, early muscle cars like a Nova or Camaro. Of course, this entire discussion is predicated on retaining any catalytic converters or other emissions devices for emissions-controlled cars.

Beyond installing an H- or X-pipe crossover into your system this is also a great opportunity to create a system that is easy to service and/or remove. Fully welded exhaust systems are excellent for eliminating leak paths but make it far more difficult to work on the car, such as servicing a transmission or changing a clutch. The classic U-shaped wire muffler clamps crimp the pipes, making them near impossible to separate.

A much better approach is the now-popular stainless steel band clamps. These come in two configurations. The butt clamps align two pipes of the same diameter together. If the pipes are accurately positioned, these clamps do an admirable job of minimizing leaks. The second style is called an overlap clamp that slides over one pipe inside another creating a step. Both band clamps allow easy disassembly of the system and they are reusable.

007MagnaFlow Tri X crossover
Compare how tight the tubes are on this MagnaFlow Tri-X crossover. The entry angle can have an effect on ease of packaging the system. To this point, MagnaFlow also offers other X-pipes using a wider entry angle for additional fitment options.

The ultimate in serviceable connections has to be the stainless steel V-band clamps. These clamps use either flat-face or stepped-face flanges that are welded to the ends of the two connecting pipes. A stainless steel band then aligns these two steel flanges and clamps them together to form a leak-free seal. The flanges can be purchased in either alloy steel or stainless and require professional welding to complete the connection. These clamps are more expensive but offer easy service, making it well worth the initial cost and effort.

We’ve covered quite a bit of technical ground in this piece, and it should be clear by now that there are very few hard and fast rules when it comes to H- and X-pipe crossovers. If you approach these systems as improvements to sound and with less attention to power improvements, you will probably be better satisfied with the results. Exhaust tuning for sound is as much art as science.

008 clamp adjoining pipes together is with these stainless steel band clamps
An excellent way to clamp adjoining pipes together is with these stainless steel band clamps. These come in both butt-clamp (upper) and overlapping pipe versions (lower). The main advantage to these clamps is that the pipes can be easily disassembled as the band clamps do not crimp the tubing.

Traditional Small-Block Chevy Firing Sequence

Firing Order 1-8-4-3-6-5-7-2

With 90 degrees of crank rotation between each sequence, this simple chart reveals how uneven pressure waves occur on a common V-8 two-plane crankshaft.

Cylinders Odd (Left Side) Even (Passenger Side)
1 Bang No Pressure Wave No Pressure Wave
8 Bang No Pressure Wave
4 Bang
3 Bang No Pressure Wave No Pressure Wave
6 Bang
5 Bang No Pressure Wave
7 Bang No Pressure Wave No Pressure Wave
2 Bang


LS Cylinder Firing Sequence

Firing Order 1-8-7-2-6-5-4-3

Cylinders Odd Side (Left) Even (Passenger Side)
1 Bang No pressure Wave No Pressure Wave
8 Bang
7 Bang No Pressure Wave No Pressure Wave
2 Bang No Pressure Wave
6 Bang
5 Bang No Pressure Wave No Pressure Wave
4 Bang
3 Bang No Pressure Wave


At first glance it appears that the LS engine offers more evenly spaced firing pulses between the left and right banks compared to the traditional small-block Chevy. But if we include the ninth cylinder in the cylinder firing then there is still a pair of pulses for each bank that fire 90 degrees apart. The difference in the LS firing order will produce a different sound compared to the traditional small-block Chevy.

009 ultimate way to join two pipes together is with a V band clamp
The ultimate way to join two pipes together is with a V-band clamp like these from Summit Racing. These require welding the flanges to each of the adjoining pipes.

Parts List

Description PN Source
Flowmaster Universal H-pipe kit, 2½” 15920 Summit
Flowmaster universal X-pipe crossover, 2½” 815953 Summit
Flowmaster universal X-pipe Scavenge, 2½” 815932 Summit
Summit H-pipe, balance tube kit, 2½” mild steel 642025 Summit
Summit H-pipe, balance tube kit, 2½” mild steel 642030 Summit
Summit H-pipe, balance tube kit, 2½” stainless 642025-SS Summit
Summit H-pipe, balance tube kit, 3” stainless steel 642030-SS Summit
Cherry Bomb universal X-pipe, 3”, mild steel 429835CB Summit
MagnaFlow Tru-X stainless , 2½” 10791 Summit
MagnaFlow Tru-X stainless crossover, 3” 10792 Summit



Borla Performance Industries
(877) 462-6752

(800) 544-4761

Granatelli Motor Sports
(805) 486-6644

Patriot Exhaust
(909) 599-5955

Summit Racing
(800) 230-3030
