Modern Tech For Vintage Engines: PerTronix Flame Thrower Distributors

By Ron Ceridono – Photography By The Author

While there is much to be said in favor of contemporary engines with the latest in computer-controlled everything, it’s hard to beat the charm of an early domestic engine. Nostalgia may be the motivation to run such a powerplant; it may the desire for simplicity or just the urge to tap into the roots of the hobby. But whatever the reason, hot rods with vintage engines are cool, but that doesn’t mean they can’t benefit from technology.

- Advertisement -
02 Pertronix has a line of Flame Thrower vintage distributor for old Chrysler, GM, and Mopar engines
Here are four of the new additions to the Flame-Thrower vintage distributor line. Left to right: 331-354 Chrysler; Ford Y-block; Cadillac 331, 365, 368, 390 (’54-’63); and Buick Nailhead V8 264,332, 364, 401, and 425.

One of the shortcomings of many early domestic engines is the ignition system. Points and condensers were fine in their day, but electronic ignitions would prove to be vastly superior; some of that proof came from an unlikely source. In the early ’70s an engineer at Per-Lux, a company that made lighting products for the trucking industry (such as those round stainless steel lights with the horizontal baffles), developed an electronic ignition module to replace points and condensers. The intended application was forklifts and other industrial engines, but it didn’t take long for the Ignitor to become a popular automotive update as well. It became known that the Ignitor provided a much more accurate trigger signal to the coil, which improved timing accuracy and ignition misfires at high rpm due to the point bounce being eliminated. The Ignitor conversions put an end to dealing with points. Something anyone who had adjusting points with a match book cover on the side of the road in the dark could appreciate.

03 Location of the vaccuum advance will depend on the rotation of the distributor
The location of the vacuum advance canister will vary depending on the direction the rotor turns. On the left is a distributor that rotates counterclockwise (CCW), the distributor on the right rotates clockwise (CW).

Read More: Vintage Vibes and Wild Paint: 1963 C10

PerTronix Ignition Modules

- Advertisement -

In 1991 the Per-Lux ignition division changed hands and PerTronix came to be. Ignition systems were the focus and things got serious. Today PerTronix offers a wide variety of ignition products, including three versions of electronic ignition modules. The original Ignitor is still popular for converting original distributors to electronic operation. Since they are almost undetectable many “restored” award winners have one under the distributor cap for the increased reliability and spark voltage they offer. The Ignitor II includes a few more features than the original Ignitor, such as a micro-controller that adjusts dwell throughout the engine’s rpm range. The result is up to four times more voltage at the plugs. For serious performance applications PerTronix offers the Ignitor III. It can produce up to five times more spark energy than a points system and includes a digital rev limiter with LED feedback and Multi-Spark all the way to redline.

04 An old hot rod trick is to spin the rotor to point at the vacuum advance
A trick almost as old as Brian Brennan to determine which way the rotor spins is to point at the vacuum advance, which will indicate the direction of rotation —this one rotates CCW.

PerTronix Coils

Ignition coils are step-up transformers that dramatically increase battery voltage to fire the spark plugs (if you’ve ever been zapped by a plug wire the increase is obvious). Inside the coil are two coils of wires, or windings. The primary winding in the center of the coil has relatively few windings, while the secondary winding that wraps around it has many more. When the points are closed, or the electronic control allows current to flow through the primary windings, a magnetic field is created. When the points open (or the electronic device that controls current flow shuts off), the magnetic field collapses and makes current flow in the secondary windings. While it stands to reason more current in the primary would make more voltage in the secondary, the current flow is limited by the ability of the points, or the electronics in place, to handle it.

05 Springs determine when the advance starts and the rate of advance
Below the rotor are the centrifugal advance weights and springs. From the factory, mechanical advance is limited to 24 degrees. The springs determine when the advance starts and the rate of advance. The silver springs start with 3 degrees of advance at 1,500 rpm with 24 degrees at 3,500 rpm.

Read More: Speak Easy Green 1932 Ford Phaeton

- Advertisement -

PerTronix offers three distinctly different oil-filled, canister-style coils. While they look virtually the same, Don Lindfors of PerTronix explains that they are identified by the ignition system they are designed for:

06 Two additional set of springs are included with each Pertronix distributor
Two additional sets of springs are included with each distributor. The copper-colored springs provide the fastest advance curve with 5 degrees at 1,000 rpm and 24 degrees at 2,000 rpm. The black springs proved the slowest curve with 3 degrees at 2,000 rpm and 24 degrees at 5,000 rpm. It is possible to mix springs to produce custom curves.

The Flame-Thrower 40,000V coils have internal resistance rated at 1.5 or 3.0 ohms. The 3.0-ohm coil should be used on PerTronix Ignitors installed on four- and six-cylinder engines while 1.5-ohm coils should be used for eight-cylinder applications. These coils can be used on virtually any inductive (non-capacitive discharge) ignition system, including points systems.

“Flame-Thrower II coils have lower resistance, 0.6 ohms for use with Ignitor II ignition systems as well as many other high-energy ignitions. The low resistance helps to produce up to 45,000 V. This higher voltage allows larger spark plug gaps for added power and better fuel economy.

07 Tuning a distributor is provided by these limiters
Another tuning option is provided by these limiters. They are used in pairs and are marked 6, 8, and 10. Using a pair of sixes limits total advance to 12 degrees, the 8s limit advance to 16 degrees, and the 10s limit advance to 20 degrees.

“Flame-Thrower III coils were developed for use with the new Ignitor III electronics. The extremely low resistance of 0.32 ohms results in 45,000 V and a coil that charges to peak current typically 30-70 percent faster than the other coils. It should be noted that these coils are compatible with Ignitor III electronics only.”

Flame-Thrower Distributors

Although the Ignitor was, and remains, an excellent method to convert a point and condenser-equipped distributor to electronic operation, PerTronix Flame Thrower Billet Distributors offer tuning advantages not often possible with vintage OEM distributors, they are also the perfect replacement for old worn-out OEM distributors. Due to today’s fuels distributor advance curves are much different than they once were. PerTronix distributors come with a variety of advance springs and limiters to customize the advance curve for optimum performance.

08 Advance limiters are installed under the advance spring with the ends wrapped around the weights
The advance limiters are installed under the advance springs with the ends wrapped around the weights.

Recently PerTronix expanded their line of vintage domestic engine Flame-Thrower distributors to include Ford Y-Blocks, early Chrysler Hemis, Buick Nailheads, early Cadillacs, Studebaker V8s, and even Corvairs. All these distributors feature PerTronix II electronics, CNC-machined 6061-T6 billet aluminum housings, and precision-machined steel shafts with upper ball bearings and lower bushings. All are equipped with coated drive gears that are compatible with OEM and retrofit roller lifter camshafts.

09 Mechanical or vacuum lockouts are also an option for performance applications
In some performance applications it may be desirable to install either the mechanical or vacuum advance lockouts—both require partially disassembling the distributor. First, the drive gear is removed by driving out the roll pin that secures it to the shaft. Note the position of the thrust washers.

Read More: Patina Paint Job; Moal Coachbuilder’s ‘32 Ford Pickup

Installing a Flame-Thrower billet distributor is plug-and-play—drop the distributor in place, connect the black wire to the negative (-) side of the coil and the red wire to the positive (+) side and that’s it. As the Ignitor and the Flame-Thrower Coil are designed to run with a full 12 V, remove the ballast resistor (or bypass the resistor wire if there is one) from the ignition wiring and you’re ready to be pointless—but pointless in a good way.
